DB150

Specification

Vehicle Part

Dimension(L*W*H)(mm):

2010mm×820mm×1130mm

Wheel Base(mm):

1250mm

Seat Height(mm):

830mm

Unladen Kerb Weight(kg):

120kg

Loading Capacity(kg):

150kg

Min Ground Clearance(mm):

200mm

Maximum speed(Km/h):

90Km/h

Front Suspension Mode:

Telescopic Shock Absorber

Rear Suspension Mode:

Double Shock Absorber

Starting Mode:

Electric/Kick

Gearshift Mode:

Foot

Clutch Mode:

Manual Clutch

Brake Mode(F/R):

Drum / Drum

Fuel Tank Capacity(L):

10L

Tyre Size(F/R):

2.75-18, 3.50-18

Wheel:

Spoke Wheel

Fuel Type:

Gasoline

Fuel Economy:

2.3L/100km

Transmission:

5-speed

Engine Part

Engine Mode:

Single cylinder, 4-stroke, air cooled

Displacement(ml):

150CC

Bore×Stroke (mm):

62mm×49.5mm

Maximum Power:

8.2kw at 8500rpm

Maximum Torsion:

9.8N.m at 7000rpm

Compression:

9.0:1

Ignition mode:

C.D.I

Optional

Displacement:

125CC, 200CC

Brake Mode:

Front Disk

Wheel:

Alloy Wheel

Remote Control:

Yes

Helmet:

Yes
